CASE NZXT H510 ELITE BLACK FAN LED RGB NEW

KEY SPECS

• Motherboard Support:Mini-ITX, MicroATX, ATX

• Enclosure Type:Compact Mid-Tower

• Case Material:SGCC Steel, Tempered Glass

DIMENSIONS

• Height:460mm / 18.11 inches

• Width:210mm / 8.27 inches

• Depth:428mm / 16.85 inches

• Weight:7.5 kg / 16.53 lb

COMPATIBILITY & CLEARANCE

• Max CPU Cooler Clearance:165mm

• Max GPU Clearance:338 - 368mm

• Front Fan & Radiator Clearance:60mm

• Vertical GPU Clearance:50.8mm

• Cable Management:19 - 23mm

FRONT I/O PORTS

• USB 3.2 Gen 2 Type-A:1

• USB 3.2 Gen 1 Type-C:1

• Headset Audio Jack:1

SMART DEVICE

• Fan Channels:3 (10W max per channel)

• NZXT RGB Connector:2 (Support up to 40 LEDs)

EXPANSION SLOTS

• Standard:7

• Vertical:2

DRIVE BAYS

• 2.5":2 + 1

• 3.5":2 + 1

FAN SUPPORT

• Front:2 x 120mm / 2 x 140mm

• Top:1 x 120mm / 1 x 140mm

• Rear:1 x 120mm

• Filters:All air intakes

RADIATOR SUPPORT

• Front:280mm

• Top:-

• Rear:120mm

FAN SPECS

• Model:Aer RGB 2 140mm

• Speed:500 - 1,500 ± 300RPM

• Airflow:30.39 - 91.19 CFM

• Static Pressure:0.17 - 1.52 mm-H₂O

• Noise:22 - 33 dBA

• Fan Connector:4-pin PWM
